Description
Power&Performance Motor 96V6000W Mid motor  Cheerdmoto or OEM
Battery 96V30AH Lithium-ion (Samsung 50S cell)Cheerdmoto or OEM
Controller 96V120A Cheerdmoto or OEM
Main cable Quick release
Display LCD 12V  Cheerdmoto or OEM
Charger 100.8V10A   Cheerdmoto or OEM
Charging time 3-4hours
Estimated Range 95km
Top Speed 115km/h
Max torque 385N.m high speed low torque

Cooling system Air cooling

Drive&Brake Drive Mode Hall throttle
Gearing 420 chainwheel
Brake 4 cylinder hydraulic disc brake Front&Rear

Mechanical Parts Frame 6061 Aluminum Alloy
Full suspension Hydraulic adjustable front fork damping stroke 203mm
Hydraulic adjustable Rear shock absober damping stroke 85mm/450LBS
Min. Ground Distance 235mm
Wheelbase 1275mm
Seat two seats,
seat for climbing , height to ground  685mm
seat for off road, height to ground  840mm
Handlebar&Stem Aluminum Alloy 31.8mm
Rim Aluminum Alloy,double wall
Spokes #65 manganese stell 10g
Tire CST,front 70/100-19, rear 90/100-16
Max load 150Kg

Accessories Headlight LED 12V water proof  quick release plug
Horn 12V
Plastic  Front&rear, PP plastic

Packing&Measurement Product size 1890mm x 730mm x 1140mm
Packing Honeycomb carton box
Carton size 166*37*86cm
Gross/Net weight 90kg/ 77kg
Container 126pcs/40HQ
